What is this tube for on a Yamaha 60LB

Platypus E65

Seaman
Joined
Mar 30, 2010
Messages
57
I just received a new Yamaha 60LB prop model that I needed to install a tiller handle on to. This tube was hanging out of the grommet hole. I couldn't find anything about it online or in any of the manuals that came with the outboard or tiller.



robert graham

Admiral
Joined
Apr 16, 2009
Messages
6,908
Looks like a speedometer tube….if you don’t have a speedometer then just leave it where it is….


99yam40

Fleet Admiral
Joined
Sep 7, 2008
Messages
9,116
is there a hole in the end piece or is it a solid plug?
if a hole, need to plug or water will come out underway
carries water pressure from lower unit front edge to indicate speed


boscoe99

Commander
Joined
Aug 22, 2013
Messages
2,058
I suspect that you are talking about an F60LB. F for four stroke.

99Yam is spot on.


Platypus E65

Seaman
Joined
Mar 30, 2010
Messages
57
Probably for a speedometer.
Looks like a speedometer tube….if you don’t have a speedometer then just leave it where it is….
is there a hole in the end piece or is it a solid plug?
if a hole, need to plug or water will come out underway
carries water pressure from lower unit front edge to indicate speed
I suspect that you are talking about an F60LB. F for four stroke.

99Yam is spot on.
Thanks everyone. Yes, it's four stroke F60.
@robert graham, the tiller installation instructions didn't say anything about it so I just tucked it inside around the bottom.
@99yam40, it was plugged.
